≥2000times
2 years
CE/RoHS/UN38.3/MSDS
black or optional
about 13.5kg
Credit Card.Paypal.TT.Escrow.Western Union
405±1*175±1*240±1mm or customized
3-7days
Specification
| NO. | Item | Specifications | |||||
| 1 | Typical Capacity | 110.0Ah @ 0.2C Discharge | |||||
| Minimum capacity | 105.6Ah @ 0.2C Discharge | ||||||
| 2 | Nominal voltage | 12.8V | |||||
| 3 | Standard Charge | CC/CV,0.2C5A,14.6V | |||||
| 4 | Standard Discharge | CC,0.2C5A, 10.0V | |||||
| 5 | End-of-charge Voltage | 14.6V±0.1V | |||||
| 6 | End-of-charge Current | 0.02C5A (At CV mode) | |||||
| 7 | End-of-discharge Voltage | 10.0V | |||||
| 8 | Charging Time | 8.0hours(standard charge) | |||||
| 9 | Quick Charge Current | 55A (0.5C5rate) | |||||
| 10 | Quick Discharge Current | 110A (1.0C5rate) | |||||
| 11 | Max Discharge Current | 220A (2.0C5rate) | |||||
| 12 | Initial Impedance | Max: 180mW | |||||
| 13 | Weight | Approx:15.50Kg | |||||
| 14 | Operating temperature | Charging: 0℃~45℃
Discharging:-20℃~60℃ |
|||||
| 15 | Storage temperature | -5℃~35℃ | |||||
| 16 | Storage Humidity | ≤75% RH | |||||
| 17 | Appearance | Without scratch, distortion, contamination and leakage | |||||
| 18 | Standard environmental condition
|
Temperature : 25±2℃
Humidity : 45-75%RH Atmospheric Pressure : 86-106 KPA |
|||||
| 19 | Temperature Dependence of Discharge Capacity
@ 0.2C Discharge |
||||||
| 25℃ | -10℃
|
0℃
|
15℃
|
25℃
|
40℃
|
||
| Relative Capacity | 50% | 80% | 90% | 100% | 100% | ||
Features
1. Built in BMS. Over charge,over discharge,short circuit,over current and over temperature.
2. High efficiency output.Deliver current up to 320A.
3. No memory effect.No need to discharge and recharge when charging
4. Environmental friendly.No heavy metals.Pollution free.
5. Long cycle life.2000 times at 100%DOD.3000 times at 80%DOD.
If you have other special requirements of the lifepo4 battery pack,welcome send messages to us and we will reply as soon as possible.
Applications
Widely used in RV, camping car, marine,boat,golf carts,sightseeing cars,solar backup,solar pv light, industrial equipment, and other deep cycle replacement.
1.OEM&ODM manufacturer with various design and one-stop battery solution.
2.Reliable quality; Factory direct price; Complete production lines.
3.Timely and professional pre-sales service and after-sales service.
4.100% test before shipment; Solid package; Fast delivery and stable shipment.
1.Where can I get the price of 12v 110ah deep cycle battery?
Please click "Send Inquiry" above or "Leave a Comment" below
We will offer you the best quote in 24 hours after we get the product specifications
such as voltage capacity application etc.
2.How can you guarantee your quality?
Normally we will send you a sample to confirm everything first.
We will make the big order exactly the same as you request.
3.What about the lead time for mass production?
It depends on your order quantity.Normally 1-2days if we have sample in stock,
5-7days for newly produced samples.10-20 day for big order.
4.What shipping method can I choose? How about the shipping time?
By Express (3-7 working days), suitable for urgent time or small quantity.
By Sea (15-30 days), it suitable for mass production.
By Air (4-7 days), from airport to airport.
