175*175*110mm
>3000 times
4.5kg
30A
Yes With BMS
TT, Credit Card, Paypal, Western Union
Cyclen offer full series of high performance 12v 24v 36v 48v lithium lifepo4 batteries for lead acid/gel/agm replacement.Support OEM ODM services and do customization service according to customers'requirements.If you are looking for new advanced lifepo4 technology, we can be your reliable supplier.Here are specifications of lifepo4 12v 32ah battery module.
|
Items
|
Parameter
|
|
|
Nominal voltage
|
12.8V
|
|
|
Typical capacity
|
32.4±1Ah( At 0.2C discharge rate)
|
|
|
Discharge
|
Normal current
|
6A
|
|
Max continuous current
|
30A
|
|
|
Maximum instantaneous current
|
120A(＜5ms)
|
|
|
Cut-off voltage
|
10V
|
|
|
Charge
|
Voltage
|
14.4±0.1V
|
|
Current
|
≤30A
|
|
|
Charge mode
|
CC/CV，please use special lithium charger
|
|
|
Charging cut-off current
|
0.65A
|
|
|
Inner resistance
|
Discharging Inner resistance
|
≤50mΩ
|
|
Operation temperature/ humidity range
|
Charge
|
0℃～+45℃
|
|
Discharge
|
When the environment temperature is higher than 45℃，please pay attention to ventilation and heat rejection.
|
|
|
Humidity
|
RH≤85%, When the environment humidity is higher than 85%，please pay attention to protect
|
|
|
Storage temperature/ humidity range
|
Temperature
|
0℃～40℃（Capacity 80%）Recommended long-term storage temperature is 15~25℃
|
|
Humidity
|
RH≤50%，Easily oxidized components note sealed
|
|
|
Protection function
|
Overcharge protection、Over discharge protection、Temperature protection
|
|
|
Shell material
|
ABS
|
|
|
Outside size
|
（175±2）mm *（175±2）mm *（110±2）mm
|
|
|
Cycle
|
Standard charge at 0.2C（A）, rest 0.5~1 h，discharge at 0.2C to cut off voltage，rest 0.5~1h,repeat the above steps until 1000
cycles.( capacity retention rate≥80%) |
|
Key Features of 12V 32Ah Lifepo4 Battery
BMS Built in Lithium ion Golf Cart Battery
Main Applications of 12v 32ah Lithium Battery Module
Cyclen is a chinese lifepo4 battery manufacturer specialized on producing high performance lithium lifepo4
battery packs and custom battery solutions.We have exported our battery packs worldwide for years.If you
are looking for lead acid/gel/agm replacement battery, we can be your reliable supplier.
Battery price depends on your quantity and specifications. Welcome to contact the Online Services.
If it's not our working time, please "Leave a Comment" below about your requirement.
We will offer you the best quote in 24 hours after we get the product specifications such as voltage
capacity application etc.
It depends on your order quantity.Normally 1-2days if we have sample in stock, 5-7days for newly
produced samples. 10-20 days for big order.
Our sales will help you choose the most cost-effective shipping methods.
By Express (3-10 working days), suitable for urgent time or small quantity.
By Sea (15-30 days), it suitable for mass production.
By Air (4-7 days), from airport to airport.
We pack one battery in one carton box, and filled with EPE foam on the top and at the bottom.
For heavier battery, we adopt wooden case.And our shipping agent has full experience in safe
transportation. We will send you pictures of the packaging before battery shippment.
Usually 2-3 years warranty (Depends on different battery model) .And we offer online support by email,
skype, whatsapp or wechat etc. If you meet problems, we have our own engineers to provide technical
guide.
