323*171*215 mm or customized
about 11kg
≥3000times
2 years
CE/RoHS/UN38.3/MSDS
black or optional
Credit Card.Paypal.TT.Escrow.Western Union
| NO. | Item | General Parameter | Remark | |
| 1 | （Model） | 32650-5Ah | （Single） | |
| 2 | Casing material for single cell | Nickel plated steel | ||
| 3 | Standard capacity（0.2C3A） | 90Ah | ||
| 4 | Mininum Capacity（1C3A） | 80Ah | ||
| 5 | Rated voltage | 12V | (Work voltage：3.20V) | |
| 6 | Max.Charge voltage | 14.6V | (Single Ave. charge Voltage：3.65V) | |
| 7 | Cut-off voltage | 10V | (Single Ave. Discharge Voltage：2.50V) | |
| 8 | Standard charge current | 18A | 0.2C3A | |
| 9 | charging Time | 5h | 0.2C3A | |
| 10 | Max Continuous discharge current | 90A | 1C3A | |
| 11 | Battery dimension | 323*171*215 mm | ||
| 12 | Total weight（Approx.) | About 10 kg | ||
| 13 | （Max, at 1000Hz.）
Impedance（Max, at 1000Hz.） |
≤ 30mΩ | ||
| 14 |
Charge method (CC/CV) |
Standard | 0℃～45℃ | |
| discharge | -20℃～45℃ | |||
| storage | -20℃～45℃ | |||
Features
1. A drop in replacement&smart sustainable solution for lead acid,agm&gel batteries.
2. Our lifepo4 batteries can be connected in series and parallel to provide power for a wide range of applications
3. Each battery has built in Battery Protection System that optimizes the performance and safety of the battery by automatically balancing cells and protecting them from being over charged and over discharged.
Typical Application
RV/Caravan, Boat/Yacht, Golf Cart, Solar Energy System, UPS,off grid energy storage and other deep cycle applications.
1.OEM&ODM manufacturer with various design and one-stop battery solution.
2.Reliable quality; Factory direct price; Complete production lines.
3.Timely and professional pre-sales service and after-sales service.
4.100% test before shipment; Solid package; Fast delivery and stable shipment.
1.Where can I get the price of the 12v 90ah lithium ion battery?
We will offer you the best quote in 24 hours after we get the product specifications
such as voltage capacity application etc
2.How can you guarantee your quality?
Normally we will send you a sample to confirm everything first.
We will make the big order exactly the same as you request.
3.What about the lead time for mass production?
It depends on your order quantity.Normally 1-2days if we have sample in stock,
5-7days for newly produced samples.10-20 day for big order.
4.What shipping method can I choose? How about the shipping time?
By Express (3-7 working days), suitable for urgent time or small quantity.
By Sea (15-30 days), it suitable for mass production.
By Air (4-7 days), from airport to airport.
