battery energy storage systems

battery energy storage systems
  • battery energy storage systems
  • 20ft container energy storage system

20ft 40ft battery energy storage systems

battery energy storage systems

Product Specification:

  • Cycle life:


  • Certificate:


  • Color:

    black or optional

  • Weight:

    about 42kg

  • Payment:

    Credit Card.Paypal.TT.Escrow.Western Union

Inquiry Now

20ft 40ft battery energy storage systems

entry name technical parameter remarks
Number of batteries 8448 -
Nominal energy


2.7 0.25C
Nominal voltage (V) 1126.4 352 × 3.2V
Nominal capacity (Ah) 2400Ah -
Working voltage

range (V)

950.4~1267.2 352 × (2.7~3.6V)


ratio (C)

0.25C -
Service life (years) >15 0.25C 90%DOD
Optimum operating

temperature range

10℃~35℃ -
Allowable operating

temperature range

—35℃~45℃  -
Operating humidity 5%~95%  -
insulation resistance >20MΩ  -
Dimension of BESS


6058*2438*2896  -
Number of battery


6+1 (combiner cabinet)  -

20ft battery energy storage system

20ft battery energy storage system

20ft battery energy storage system

battery energy storage system

battery energy storage systemcontainer energy storage system

Battery energy storage systems Description:

The off-grid photovoltaic power generation system is a new type of power source that generates electricity from photovoltaic components, manages the charge and discharge of the battery through the controller, and provides electrical energy to the DC load or the inverter to provide electrical energy to the AC load. It is widely used in plateaus, islands, remote mountainous areas and field operations where the environment is harsh. It can also be used as a power supply for communication base stations, advertising light boxes, street lights, etc.


Performance characteristics:

1. The use of photovoltaic systems can achieve better utilization of renewable energy;

2. Has a high system practicability;

3. Compared with a system with a single-use diesel generator, it has less maintenance and uses less fuel;

4. Better flexibility in load matching. Photovoltaic systems can be applied to a wider range of load systems, for example, larger AC loads, shock loads, etc. can be used. It can also better match the load and the power generation of the system.

battery energy storage systems Advantage:

1.Integrated Design for Energy Storage

2.Lithium Battery Design with BMS/EMS

3.Factory Automatic Emergency Backup

4.Automatic Diesel Generator Supplement

5.High ROI for Selling Energy to Utility


Mainly used for off-grid solar system storage, telecommunication, BTS, central data center, General macro base station, New energy base etc.
48V 100ah Lifepo4 Battery Pack
battery energy storage system

portable solar power station 12v

1.OEM&ODM manufacturer with various design and one-stop battery solution.

2.Reliable quality; Factory direct price; Complete production lines.

3.Timely and professional pre-sales service and after-sales service.

4.100% test before shipment; Solid package; Fast delivery and stable shipment.

 →Learn More About US

portable solar power station 12v

48V 100ah Lifepo4 Battery Pack

portable solar power station 12v

1.Where can I get the price of the 20ft battery energy storage systems?

   Welcome to contact the Online Services. If it's not our working time,

    please click "Send Inquiry" above or "Leave a Comment" below,

    We will offer you the best quote in 24 hours after we get the product specifications

    such as voltage capacity application etc.

2.How can you guarantee your quality?

   Normally we will send you a sample to confirm everything first.

   We will make the big order exactly the same as you request.

3.What about the lead time for mass production?

    It depends on your order quantity.Normally 30days if we have sample in stock,

   40days for newly produced samples.60dayscontainer energy storage system for big order.

4.What shipping method can I choose? How about the shipping time?

    By Express (3-7 working days), suitable for urgent time or small quantity.

    By Sea (15-30 days), it suitable for mass production.

    By Air (4-7 days), from airport to airport.
