≥3000times
L260*w170*h230mm
2 years
CE/RoHS/UN38.3/MSDS
bluck
approx:2.5kg
Credit Card.Paypal.TT.Escrow.Western Union
standard carton packaging or according customer's special needs
3-7days
|
Normal performance
|
|||
|
NO
|
Item
|
General Parameter
|
Remark
|
|
1
|
Model
|
18650 3.2Ⅴ20Ah
|
Single
|
|
2
|
Casing material for single cell
|
Nickel plated steel
|
|
|
3
|
Standard capacity(0.2C5A)
|
20Ah
|
|
|
4
|
Rated voltage
|
12.8V
|
3.20V(Work voltage:3.20V)
|
|
5
|
Max.Charge voltage
|
14.6V
|
3.65V(Single Ave. charge Voltage)
|
|
6
|
Cut-off voltage
|
10V
|
2.50V(Single Ave. Discharge Voltage)
|
|
8
|
Standard charge current
|
10A
|
0.5C
|
|
9
|
charging Time
|
About 3h
|
|
|
10
|
Max Continuous discharge current
|
20A
|
1C
|
|
11
|
Peak discharge current
|
40A
|
2C 10seconds
|
|
12
|
Battery dimension
|
L260*w170*h230mm
|
|
|
13
|
(Approx.)Total weight(Approx.)
|
About 2.5kg
|
|
|
14
|
(Max, at 1000Hz.)Impedance(Max, at 1000Hz.)
|
≤ 20mΩ
|
|
|
15
|
(CC/CV) Charge method (CC/CV) |
Standard
|
0℃~45℃
|
|
discharge
|
-20℃~45℃
|
||
|
storage
|
-20℃~45℃
|
||
Features of lifepo4 12v 20ah
Application
1.OEM&ODM manufacturer with various design and one-stop battery solution.
2.Reliable quality; Factory direct price; Complete production lines.
3.Timely and professional pre-sales service and after-sales service.
4.100% test before shipment; Solid package; Fast delivery and stable shipment.
1.Where can I get the price of lifepo4 12v 20ah?
Click "Inquiry Now" above or "Leave the Message below". We will offer you the best quote
in 12 hours after we get the product specifications such as voltage capacity application etc
2.How can you guarantee your quality?
Normally we will send you a sample to confirm everything first.Trial oder is available.
And we will make the big order exactly the same as you request.
3.What about the lead time for mass production?
It depends on your order quantity.Normally 1-2days if we have sample in stock,
5-7 days for newly produced samples.10-20 days for big order.
4.What shipping method can I choose? How about the shipping time?
By Express (3-7 working days), suitable for urgent time or small quantity.
By Sea (15-30 days), it suitable for mass production.
By Air (4-7 days), from airport to airport.
