≥3000times
3year
CE/RoHS/UN38.3/MSDS
black
Credit Card.Paypal.TT.Escrow.Western Union
customized
standard carton packaging or according customer's special needs
3-7days
|
Normal performance
|
|||
|
NO
|
Item
|
General Parameter
|
Remark
|
|
1
|
Model
|
IFR 32650-5Ah
|
Single
|
|
2
|
Casing material for single cell
|
Nickel plated steel
|
|
|
3
|
Standard capacity(0.2C5A)
|
200Ah
|
|
|
4
|
Rated voltage
|
48V
|
3.20V(Work voltage:3.20V)
|
|
5
|
Max.Charge voltage
|
54.75V
|
3.65V(Single Ave. charge Voltage)
|
|
6
|
Cut-off voltage
|
37.5V
|
2.50V(Single Ave. Discharge Voltage)
|
|
8
|
Standard charge current
|
80A
|
0.4C
|
|
9
|
charging Time
|
About 3-4h
|
|
|
10
|
Max Continuous discharge current
|
100A
|
0.5C
|
|
11
|
Peak discharge current
|
160A
|
1.05C seconds
|
|
12
|
Battery dimension
|
710±1*412±1*268±1mm
|
|
|
13
|
(Approx.)Total weight(Approx.)
|
About 115kg
|
|
|
14
|
(Max, at 1000Hz.)Impedance(Max, at 1000Hz.)
|
≤ 20mΩ
|
|
|
15
|
(CC/CV) Charge method (CC/CV) |
Standard
|
0℃~45℃
|
|
discharge
|
-20℃~45℃
|
||
|
storage
|
-20℃~45℃
|
||
Performance
1.Discharge performance in normal temperature
Discharge capacity /standard capacity×100%
(A)0.2C5A ≥100%
(B)1C5A ≥90%
2.Charging keep ability in normal temperature
Rest capacity≥standard capacity *90%
3.Cycle life
More than 3000 cycle times. Capacity≥ Standard capacity *80%
4.Storage performance
Capacity can be kept ≥80% Storage for 12months.
Features
1.Long lifespan>3000 cycles
2.Lighter in weight but heavier on power.
3.Most safe lithium battery with car level standard
4.In-built smart BMS with multiprotection
5.Modular and quick plug desigh makes it easy to use
1.OEM&ODM manufacturer with various design and one-stop battery solution.
2.Reliable quality; Factory direct price; Complete production lines.
3.Timely and professional pre-sales service and after-sales service.
4.100% test before shipment; Solid package; Fast delivery and stable shipment.
1.Where can I get the price of 48v 200ah lithium ion battery?
Please click "Send Inquiry" or "Leave a Comment" below
We will offer you the best quote in 24 hours after we get the product specifications
such as voltage capacity application etc
2.How can you guarantee your quality?
Normally we will send you a sample to confirm everything first.
We will make the big order exactly the same as you request.
3.What about the lead time for mass production?
It depends on your order quantity.Normally 1-2days if we have sample in stock,
5-7 days for newly produced samples.10-20 day for big order.
4.What shipping method can I choose? How about the shipping time?
By Express (3-7 working days), suitable for urgent time or small quantity.
By Sea (15-30 days), it suitable for mass production.
By Air (4-7 days), from airport to airport.
